Feature Rich ESC Designed for Ultimate Performance

The Cayote Crest 8 1/8 200A Sensored Brushless ESC is engineered for high-performance RC applications, delivering precise power control and reliability. With advanced cooling technology and customizable settings, this ESC adapts to various racing conditions. Additionally, this ESC includes an optional glitch buster to help smooth out voltage fluctuations and interference. Whether you're pushing the limits on the track or tackling challenging terrain, the Crest 8 ESC provides the control and durability needed for intense competition.

About the Crest 8 Brushless ESC

Powerful Boost & Turbo Timing

Featuring a super large 48° boost and turbo timing, the Crest 8 ESC maximizes power output while optimizing motor efficiency. This advanced timing system enhances acceleration and top speed, making it ideal for competitive racing. The fine-tuned performance ensures smoother throttle response and increased stability during high-speed runs.

Comprehensive Data Monitoring

With offline data recording, users can track ESC performance and analyze key metrics to improve their driving strategy. This function allows racers to make precise adjustments based on real-time data, helping to optimize power output and battery usage. By reviewing recorded data using the Cayote Xlink Multifunction LCD Program Box (CYECPB01 - sold separately)*, users can fine-tune their setup for consistent and reliable results.

Advanced Protection & Customization

Equipped with over thirty-three adjustable parameters, the Crest 8 ESC offers extensive tuning options to match various racing styles. Multiple protection functions such as low voltage and motor overheat protection safeguard your electronics from damage. The built-in professional reversing shutdown system ensures precise control, making it a reliable choice for demanding racing conditions.

Features:

Super large 48° boost and turbo timing
Offline data recording for performance tracking
Over thirty-three adjustable parameters
Built-in super switching mode BEC
Smooth and stable power delivery
Professional reversing shutdown system
Multiple protection functions for long-term reliability
Advanced cooling system for heat dissipation
Lightweight and durable construction
Optimized for competitive racing

Includes:

(1) Crest 8 1/8 200A Sensored Brushless ESC
(1) Glitch Buster
(1) Sensor Cable
(3) Black 10AWG Wire Connectors
(1) Black 13AWG Wire Connector
(1) Red 13AWG Wire Connector
(1) Heat Shrink Tube Set
(1) Double-Sided Mounting Tape
Instruction Manual

Specifications:

Suggested Application	1/8 Buggies, Truggies & Trucks
Motor Type	Brushless - Sensored/Sensorless
Input Voltage	2-4S LiPo (7.4-14.8V)
Continuous Current	200A
Peak Current	1080A
Dimensions (LxWxH)	2.24x1.64x1.57in (56.8x41.6x40mm)
Weight	4.3oz (122g)
Motor Limits	4268/4274 3000kV Maximum with 4S Lipo
BEC Voltage	6.0/7.4V
BEC Continuous Current	8A
BEC Peak Current	12A
Motor Connector	Solder
Battery Connector	Solder
Motor Wire	10AWG
Battery Wire	13AWG
Throttle Wire	-
Programmable	Yes, with Cayote Xlink Program Box*

*Tech Note: The Cayote Xlink Multifunction LCD Program Box (CYECPB01 - sold separately) is required to read the data. Optionally, you can also use the Cayote BTune 1/10 ESC Bluetooth Module (CYECBM01 - sold separately) to connect to the Cayote Team App and set the parameters and update the firmware.
