The NO AUX MOD Kill Switch is 'NOT' Compatible with any SPEKTRUM RADIO SYSTEM, but the Normal MOD Racing Kill Switch is compatible with Spektrum via Aux Kill Button Assign.

MOD Racing Kill Switch has one purpose; to reliably kill your 5th scale engine quickly and safely. A kill switch you can trust from beginning to the end of your race.

NO AUX Kill Switch will activate under three conditions:

Shut off Radio - This is the Main Way to Kill The NO AUX Kill Switch
Total Voltage Loss or Low Voltage under 3.0 Volts (should never reach this unless loss of a cell or cells)
Total Signal Loss (Transmitter loses signal / remote turns off / receiver fails)

Simple Design:

Plug and Play as Long as you have an open port and a power switch on your radio when you shut it off it kills the car.
No dip switches
No parameters to choose
Simply connect to ignition coil and receiver no need to set AUX Channel
This is Perfect for people that have run out of ports on their receiver or are not familiar with setting up their radio system.

Pro Tips:

When using the Y splitter can only split off of servos (port 1 / 2 ) do not try and split off of power or transponder will not work properly.
Only works with name brand higher end radios including Sanwa, Futaba, KO Propo
May have issues with Old radios past 2-3 generations old.
Currently cannot get to work with Latest Spektrum or Hitec Radio, both radios work with the MOD standard Kill Switch.

Specs:

Weight: 10 grams for the unit itself (believe to be the lightest on the market)
Dimensions: 16x19x14 mm (believe to be the smallest footprint- less then a nickel in comparison)
Latency: 0.10 Seconds

Package Contents:

1 x Kill Switch with external signalling LED light
1 x Motor Ignition Coil Kill switch tether (plugs into kill switch)
1 x Y splitter

Satisfaction Guarantee:

Guaranteed to work with your RC 5th Scale vehicle that has an ignition coil
Trust is key and if the MOD Racing Kill Switch does not respond or perform its kill function properly simply send it back and we will refund your purchase price of item.

Why Now?:

Came out of necessity as many of the major brand kill switches we have seen throughout the years have experienced being untrustworthy and would kill the vehicle without cause creating doubt. (We tried many as well, none were 100 over 100)

With doubt in many peoples minds, many would rather risk run away then lose a race due to an unworthy kill switch shutdown.

Runways can happen at any time for a plethora of reasons.

Throttle servo failure, battery loss with throttle in open position, carburetor butterfly failure and mechanically sticks open, throttle bar failure, rock stuck in throttle bar, receiver failure, ect.

Needed For 5th Scale Racing to Grow:

A run away 5th scale is a huge liability and having a reliable source of control over its shutdown at any point in time is a needed feature that we all need to have in order for us to limit the liability of racing this size of vehicle.
With a reliable racing kill switch this expands our horizons for new venues and gives people more of a sense of security that their race rig will not be destroyed at a drop of a pin.

Cheap Insurance.

A run away car can cause hundreds and sometimes thousands of dollars worth of damage to both the rc vehicle itself and to other peoples property. And in the unfortunate event it can also cause physical harm to people if caught in its path.

Winning Championships:

MOD Racing Kill Switch has been Trusted to be onboard while in the biggest of races (something we have avoided with other kill switch products as they could fail at any time)

2019 MOD Pro Truck Series Champion
2019 Pro Truck 1st Place West Coast Nationals
2020 Worlds Pro Truck 2nd Place
2020 Multiple MOD Series Pro Race Wins
2020 Midwest Shootout Pro Truck and Buggy Champion
2021 Monster Cross 3 Hour Enduro Win
2021 Buggy Worlds WIn
2021 Truck Worlds Win
2022 Monster Cross 3 Hour Enduro WIn (2 Peat)
2022 Worlds Win Truck / Buggy Pro

Tested:

2s Radio system and Servos - Approved
4s Big Hitec with regulator to receiver - Approved
Both Reed and Piston Port Motors - Approved
9 months of continuous testing
Flawless Zero failure rate in racing situations

NGK CMR7H Spark Plug
